Rosemount 3051CD3A02A1JM6K5S5Q4 with integral manifold model 0305RC52B11B424(Manifold details

Product Description:

The Pressure Transmitter Manifold is a high-performance instrument designed to provide accurate and reliable pressure measurement in demanding industrial environments. Manufactured with premium materials such as 316L stainless steel (SST), Alloy C-276, Alloy 400, tantalum, gold-plated 316L SST, and gold-plated Alloy 400, this manifold ensures exceptional corrosion resistance and durability. These material options allow the manifold to withstand harsh chemical environments and extreme operating conditions, making it suitable for a wide range of applications.

One of the key advantages of this Pressure Transmitter Manifold is its extensive temperature range, capable of operating from -40 to 150 °C. This makes it ideal for use in processes involving fluctuating or extreme temperatures without compromising accuracy or structural integrity. Additionally, the manifold supports high-temperature media, enabling it to function effectively in applications where the temperature of the measured media is elevated, further enhancing its versatility.

The manifold is designed to accommodate Emerson pressure transmitters, such as the highly regarded 3051CD1A02A1JM6K5S5Q4 and 3051CD3A22A1AB4M5Q4 models. These transmitters are known for their precision, reliability, and advanced features, making them perfect partners for the manifold. When combined with the 305RC32 5-Valve manifold, users benefit from a streamlined installation that simplifies maintenance, calibration, and operational procedures. The 5-valve configuration allows for easy isolation, equalization, and venting, which enhances safety and reduces downtime during maintenance activities.

Communication flexibility is another standout feature of this Pressure Transmitter Manifold system. It supports multiple communication protocols, including the classic 4-20 mA HART®, WirelessHART®, FOUNDATION™ Fieldbus, PROFIBUS® PA, and the 1-5 V Low Power HART®. This diverse protocol compatibility ensures seamless integration with various control and monitoring systems, providing users with real-time data and advanced diagnostics capabilities. Whether working in traditional or modern smart plant environments, this manifold facilitates efficient data transmission and process control.

Pressure measurement capabilities are robust and versatile, with the manifold able to handle maximum pressures up to 2000 psi (137.89 bar) differential, 2000 psig (137.89 bar) gage, and up to 4000 psia (275.79 bar) absolute. This wide pressure range meets the requirements of many industrial processes, including oil and gas, chemical processing, power generation, and water treatment. The ability to measure differential, gage, and absolute pressures makes it a highly adaptable solution for complex pressure monitoring needs.

In summary, the Pressure Transmitter Manifold featuring Emerson’s 3051CD1A02A1JM6K5S5Q4 and 3051CD3A22A1AB4M5Q4 transmitters paired with the 305RC32 5-Valve assembly offers a comprehensive, reliable, and versatile solution for pressure measurement. Its superior material construction, wide temperature range, support for high-temperature media, multiple communication protocols, and extensive pressure capacity make it an excellent choice for a broad spectrum of industrial applications. Users can depend on this manifold system to deliver precise measurements, ease of maintenance, and seamless integration into modern process control infrastructures.

Features:

• Product Name: Pressure Transmitter Manifold
• Model: 3051CD1A02A1JM6K5S5Q4
• Compatible with Differential pressure transmitter Rosemount
• Diagnostics Features:
  • Basic Diagnostics
  • Process Alerts
  • Loop Integrity Diagnostics
  • Plugged Impulse Line Diagnostics
• Communication Protocols Supported:
  • 4-20 MA HART®
  • WirelessHART®
  • FOUNDATION™ Fieldbus
  • PROFIBUS® PA
  • 1-5 V Low Power HART®
• Suitable for High Temperature of Media
• Compatibility: Compatible With Most Pressure Transmitters
• Customized Support Available:
  • OEM
  • ODM

Technical Parameters:

Applications:

The Rosemount Pressure Transmitter Manifold, model number 3051CD0A22A1AM5B4DFE5, is a high-quality product originating from China, designed to provide reliable and precise pressure measurement in various industrial applications. This manifold is engineered to be directly mounted, offering ease of installation and maintenance. It supports a wide temperature range from -40 to 150 °C, making it suitable for environments with high-temperature media. This capability ensures durability and accurate performance even under extreme conditions.

This product is particularly compatible with most pressure transmitters, including popular Emerson models such as the 3051CD2A22A1AB4M5Q4 and the 3051CD2A02A1JM6K5S5Q4, ensuring seamless integration into existing systems. The manifold also pairs effectively with the 305RC32 5-Valve configuration, which is widely used for isolating, calibrating, and venting pressure transmitters. This compatibility enhances operational flexibility and simplifies maintenance procedures in process control environments.

In practical applications, the Rosemount Pressure Transmitter Manifold is ideal for use in industries such as oil and gas, chemical processing, power generation, and water treatment plants. It is commonly utilized in process control systems where accurate pressure measurement and control are critical for safety and efficiency. The manifold’s direct mount design reduces potential leak points and minimizes installation space, which is advantageous in compact or complex piping setups.

The output signal of 4-20 mA HART protocol provided by this manifold ensures reliable communication with control systems, enabling real-time monitoring and diagnostics. This feature is essential for predictive maintenance and minimizing downtime in industrial operations. Additionally, the manifold’s robust construction and resistance to high temperature media make it suitable for harsh operating conditions, including steam and high-pressure fluid applications.

Overall, the Rosemount 3051CD0A22A1AM5B4DFE5 Pressure Transmitter Manifold is a versatile and dependable solution for enhancing pressure measurement accuracy and operational efficiency. Its compatibility with Emerson’s established transmitter models and valve configurations makes it a preferred choice for engineers and technicians aiming for optimal process control and instrumentation performance.
